P-HS-15(T)
The P-HS-15(T) 15W aluminum horn loudspeaker is renowned of high reliability and superb efficiency. It is suitable for all industrial environments and public areas.
To meet your requirements that fall outside of hazardous rated areas, Guardian Telecom offers a wide variety of General Area, indoor/outdoor exterior Speakers & Ringers. From metal to plastic and horn to ceiling styles.
Guardian Telecom manufactures supplies and distributes a wide selection of Explosion Proof, Hazardous Area, ATEX-IEC and General Area Ringers and loudspeakers from leading manufacturers around the world to meet the unique demands of Industrial Communication projects.
Guardian’s represents DNH, E2S, Federal Signal, MEDC and TOA, and has access to an extensive range of other world class leading manufacturers.
Guardian trained and qualified personnel work with customers to specify individual product or total project solutions and make informed purchasing decisions based on budget, technology, applications and relevant standards.
Specifications
Images
Standards Compliance
CE
A product complies with essential requirements of the relevant European health, safety and environmental protection legislation, in practice by many of the so-called Product Directives.
Allows for free trade between member states including EFTA & European Union (EU) single market.
GOST RU C-NO.MJI02.B.00125
GOST
RU C-NO.MJI02.B.00125
Series Hazardous
Visit manufacturer’s website or contact manufacturer for details.
NS-EN ISO 9001:2015
DNH A/S Den Norske Høyttalerfabrikk A/S Kragerø, Norway has implemented and maintains a Quality Management System which fulfills Nemko’s provisions for Management System Certification and the requirements of the following standard NS-EN ISO 9001:2015.
The certificate covers the following activities:
Design/development, purchase, production and marketing of Loudspeakers, Beacons and Junction Boxes – including versions for hazardous locations (Ex).
Visit manufacturer’s website or contact manufacturer for details.
Russian Fire Certificate С-№.ПБ34.В.00542
Russian Fire Certificate
С-№.ПБ34.В.00542
DNH
Visit manufacturer’s website or contact manufacturer for details.
Product Features
- Manufactured by DNH
- Horn loudspeaker
- 15 W
- Aluminum alloy / RAL 7031
- (PA-6) Cable diameter 8 – 13 mm
- Brackets and all outside nuts are stainless steel
- 70/100 Volt combined transformer:
Primary connections:
100 V 5 (White) : 8 (Red)
70 V Move red wire from 8 to 7
Secondary nominal tappings:
1 : 4 15.0 W
1 : 3 8.0 W
2 : 4 5.0 W
1 : 2 4.5 W
3 : 4 2.5 W
2 : 3 1.0 W
- 8 ohm version available
- IP-rating 67
- Rated / maximum power 15 W / 20 W
- SPL 1W/1m 107 dB
- SPL rated power 118 dB
- Effective frequency range 350 – 7500 Hz
- Dispersion (-6dB) 1kHz / 4kHz 150° / 40°
- Operating temperature -58°F to +302°F / (-50°C to +150°C)
- Order number: P-HS-15(T)
